Single-acting Ultra-thin Separate Jack

	Rated Lifting Force:10-150 ton
	Brand:LONGSHENG®
	Warranty: 12 months

~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~

Single-acting Ultra-thin Separate Jack - LSSC

1.Ends of grooved plunger no need of saddle

2.Baked enamel finish for increased corrosion resistance

3.Single-acting, spring return

4.Some model have handle for easy carrying

5.All models are equipped with quick connector and dust cap.
6.In order to extend the life of our Single-acting Hydraulic Jack, increasing dust-proof ring.

~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~

Model	Capacity	Stroke L	Body height H	Outer diameter Y(X)	Hydraulic oil capacity	Cylinder rod diameter D1	Fuel tank internal diameter D2	NW
Model	(Ton)	(mm)	(mm)	(mm)	cm 3	(mm)	(mm)	(Kg)
LSSC10-11	10	11	44	83*60	18	35	45	1.3
LSSC20-12	20	12	52	102*80	32	50	63	3
LSSC30-13	30	13	58	117*95	55	60	76	4.6
LSSC50-16	50	16	67	150*125	99	80	100	6.6
LSSC75-16	75	16	79	177*152	164	100	122	11.6
LSSC100-16	100	16	87	203*179	203	112	140	14.2
LSSC150-16	150	16	95	236*212	317	145	172	25.6

The Similar Products:


Single-acting Thin Separate Jack -- LSSB	Single-acting Hydraulic Jack -- LSSA	Single-acting Self-locking Hydraulic Jack -LSJL

~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
