Anti-overload Lever Hoists -HSH-LH
 |
Capacity:0.75-9 ton |
| Lifting Hight：1.5 m | |
| Brand:LONGSHENG® | |
| Warranty: 12 months |
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
Anti-overload Lever Hoists-HSH-LH
1,Beautiful appearance
2,Wide hook opening and dimension
3,Stronger lever handle
4,Bottom hook with the rolling bearing
5,Overload protection can be provided
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
| Model | HSH-0.75LH | HSH-1.5LH | HSH-3LH | HSH-6LH | HSH-9LH | |
| Capacity(t) | 0.75 | 1.5 | 3 | 6 | 9 | |
| Lifting Height (m) | 1.5 | |||||
|
Minimum distance between two hooks (mm) |
320 | 380 | 450 | 480 | 500 | |
| Rated pulling force(KN) | 180 | 380 | 450 | 480 | 500 | |
| No. of load chain | 1 | 1 | 1 | 1 | 1 | |
| Diameter of load chain(mm) | 6 | 8 | 10 | 10 | 10 | |
| Main Size | A | 148 | 172 | 200 | 200 | 200 |
| B | 90 | 98 | 115 | 115 | 115 | |
| C | 136 | 160 | 180 | 235 | 335 | |
| D | 40 | 52 | 60 | 68 | 85 | |
| K | 28 | 38 | 42 | 50 | 57 | |
| L | 250 | 300 | 375 | 375 | 375 | |
| Net weight(kg) | 8 | 12.8 | 18 | 28.5 | 45 | |
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
