High Pressure Single Acting Hand Pump

High Pressure Single Acting Hand Pump Brand:LONGSHENG®
Warranty: 12 months

~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
High Pressure Single Acting Hand Pump -LSPS


High Pressure Single Acting Hand Pump is a new type of portable hydraulic pump, its novel design, body compact, easy to carry, especially suitable for mobile places.

1,Two-speed action design, built-in sophisticated high-and-low-voltage-automatic -switching valve,provides high flow at low pressure, rapid oil-filled, save time, improve efficiency;
2,Double-sets plunger design,stable to bear the force, a small handle force, greatly reducing the labor intensity;
3,Using aerospace aluminum alloy material, light weight, high strength, corrosion resistance and other characteristics, and single-acting jack supporting the use of thin separation
4,High pressure hand pump is also applicable to the use of hydraulic test in mining site, workshops, laboratories, etc.

High Pressure Single Acting Hand Pump High Pressure Single Acting Hand Pump High Pressure Single Acting Hand Pump
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
Model Rated
pressure
(MPa)
Output
of oil
per stroke(cm³)
Fuel tank
capacity
(cm³)
Working oil
capacity
(cm³)
Handle
force (N)
Size (mm) NW
Low High Low pressure High pressure L W H Output Interface kg
LSPS7-1 2.5 70 32 2.5 1670 1440 300 577 120 170 3/8“NPT 6.3
LSPS7-2 2259 1980 577 120 170 8
LSPS7-3 3580 3240 582 200 170 10
LSPS7-4 6480 5860 667 250 172 14.5
LSPS10-1 1.5 100 32 2.5 1670 1440 350 577 120 170 1/4“BSP 6.3
LSPS10-2 2259 1980 577 120 170 8
LSPS10-3 3580 3240 577 140 190 10
LSPS16-1 1.5 160 32 2.5 1670 1440 375 577 120 170 1/4“BSP 6.3
LSPS16-2 2259 1980 577 120 170 8
LSPS16-3 3580 3240 577 140 190 10
LSPS20-1 1.5 200 32 0.9 1670 1440 400 577 120 170 1/4“BSP 6.3
LSPS20-2 2259 1980 577 120 170 8
LSPS20-3 3580 3240 577 140 190 10
LSPS28-1 2 280 32 0.9 1670 1440 450 577 120 170 3/4”-16UNF 6.3
